HKS Intercooler Upgrade (17-21 Civic Type-R) (HKS13001-AH005)

After extensive research, HKS noticed that the stock intercooler in the Civic Type-R was simply insufficient to handle the pressure generated by the K20C turbocharged engine. This was leading to engine intake temperatures rising to nearly 90°C.

The newly designed HKS Civic Type-R intercooler core is 100mm wide and has a capacity roughly 200% greater than the stock intercooler. This large core has shown an overwhelming increase in cooling performance.

They also saw that the stock intercooler piping layout had a sharp bend, so the intake air did not flow smoothly and lead to boost pressure loss. They've answered this by integrating a superior piping design to realize smooth air flow and reduce this loss.

Features

• Greatly increased coolant capacity
• Smoother piping on the ends to reduce pressure loss
• Overwhelming increase in cooling performance

Please Note: Minor modification of the fan shroud and rubber part that comes in contact with the core is required.

Applications

• 2017 - 2021 Honda Civic Type-R

Specifications

• Dimensions: 695mm x 178mm x 100mm

What's In The Box?

• 1 - HKS Intercooler Upgrade

Warranty

• Manufacturer Standard Warranty
